ATN Blaze Trek 319 Thermal Monocular | 2-16x | TIMNBLT319

The ATN Blaze Trek 319 is a compact thermal monocular designed for extended outdoor observation. It provides variable magnification, onboard photo and video capture, and wireless connectivity for field use. The unit is engineered for portability and extended operation with an integrated rechargeable battery and USB Type-C charging. Common applications include wildlife observation and search-and-rescue/field assessment tasks.

Product Specifications

• The pixel size of the thermal sensor is 12 µm for enhanced thermal sensitivity.
• The NETD rating is <25 mK, indicating high thermal sensitivity.
• The optical magnification range is 2–16x to adapt to short- and mid-range observation.
• The device operates at a frame rate of 50 Hz.
• The display is a 800×600 AMOLED screen for clear viewing of thermal imagery.
• The field of view measures 14.4° x 10.8°.
• The eye relief is 15 mm for comfortable viewing.
• Available viewing palettes include White Hot; Black Hot; Rainbow; Iron Red; Alarm.
• The unit includes built-in Wi‑Fi and app connectivity for streaming and media control.
• The internal storage is 32 GB for photos and video.
• Battery is an integrated rechargeable Li‑ion pack with USB Type-C charging.
• The ingress protection rating is IP67 for resistance to dust and temporary immersion.
• The listed weight is 0.7 lb (310 g) for easy portability.
• The objective lens diameter is 19 mm.
• The UPC is 658175124696.

The Blaze Trek 319 balances portability with functional features expected in modern thermal monoculars: variable magnification, multiple color palettes, onboard recording, and smartphone connectivity. Its compact form factor and integrated features make it suitable for long field days where mobility and unattended data capture matter.
